AKW Close Coupled Std Doc M Pack TMV3 Tap Stainless Dark Blue (28314SDB)

The AKW Close Coupled Standard Doc M Pack with TMV3 Tap in Stainless Dark Blue (Doc M Pack 5, 28314SDB) is the thermostatic version of AKW's Standard Close Coupled Doc M pack, supplied with epoxy resin coated stainless steel grab rails in dark blue. The Navlin Doc M rimless close coupled pan has a 480mm seated height and extended 750mm projection, and the 400mm finger rinse basin is fitted with a WRAS-approved TMV3 thermostatic mixer tap.

• WRAS-approved TMV3 thermostatic mixer tap guards against scalding
• Rimless pan, 480mm seated height, 750mm projection - Doc M compliant
• Water-saving close coupled cistern with spatula lever flush and screw-down lid
• 400mm two tap hole finger rinse basin with blanking plug
• Dark blue epoxy resin coated stainless steel grab rails supporting up to 23.5st (150kg)
• Dark blue rails have a low light reflectance value, giving strong contrast against white sanitaryware and pale walls
• Fold-up rail supports up to 30st (200kg) with adjustable leg and optional roll holder
• Dark blue ergonomic toilet seat with lid, soft-close hinges and seat lugs

In the box

• 1 x Navlin Doc M raised-height close coupled toilet pan (750mm)
• 1 x Navlin Doc-M cistern with lever flush and screw-down lid
• 1 x Dark blue ergonomic toilet seat with lid
• 1 x Navlin Doc M finger rinse wash basin, 400mm, two tap holes
• 1 x TMV3 WRAS approved thermostatic mixer tap
• 4 x 600mm straight grab rails, dark blue epoxy coated stainless steel
• 1 x 450mm straight grab rail, dark blue epoxy coated stainless steel
• 1 x Fold-up rail with adjustable leg and optional toilet roll holder

Product Details

Technical Downloads

AKW Doc M Brochure (PDF)

Product Codes & Barcodes
