AKW Navlin Raised Height Close Coupled 750mm WC Suite Lever Flush (28324)

AKW Navlin Raised Height Close Coupled 750mm WC Suite (28324)

The AKW Navlin raised-height close coupled 750mm WC suite combines an accessible 480mm seat height with an extended 750mm projection and lever flush, in white vitreous china to match the Navlin range.

Key features

• Complete suite - close coupled pan and lever-flush cistern supplied together
• Raised height - 480mm seat height (Doc M / Part M)
• 750mm projection - extended reach for easier access
• Lever flush - simple, easy-to-operate flush
• Vitreous china - hard-wearing and hygienic

In the box

• Raised-height close coupled toilet pan (750mm)
• Cistern with lever flush

Toilet seat available separately.

Dimensions & specifications

• Seat height: 480mm (Doc M / Part M)
• Pan width: 455mm
• Pan projection: 750mm
• Overall height (to cistern top): approx. 896mm
• Flush: Lever
• Material: Vitreous china
• Colour: White

Navlin WC suite range

• Raised height low level (lever) - 28322
• Raised height low level (push button) - 28322PB
• Raised height CC 650mm (lever) - 28323
• Raised height CC 650mm (push button) - 28323PB
• Raised height CC 750mm (lever) - 28324
• Raised height CC 750mm (push button) - 28324PB
• Comfort height CC - 28325
• Standard height CC - 28327
• Standard height low level (push button) - 28326
• Standard height low level (lever) - 28337
• Standard height low level (lever, PP seat) - 28407
